Speed Rail Dimensions Come Down to Three Bottles a Foot

Three bottles per foot, and the one-line test for which speed rail you meant

Three bottles per linear foot. Cabaret Design Group puts the average liquor bottle at four inches in diameter, which gives a four-inch pitch per bottle — the number that makes every other speed rail dimensions question answerable with arithmetic rather than a phone call to the supplier.

That four inches isn't a guess. Cabaret Design Group puts the average liquor bottle at four inches in diameter, and a single-tier rail stores bottles shoulder to shoulder, so the pitch and the diameter are the same figure. Divide any rail length by four. A 15-inch rail gives you three and change.

Which speed rail did you actually mean?

Search the phrase and most of what comes back is aluminium pipe for film rigging — hollow high-strength tube, most often cited in nominal 1-1/4 inch and 1-1/2 inch sizes, where, as FilmSpeed explains, the number refers to internal diameter and a "1-1/4 inch" tube measures close to 1-5/8 inch on the outside, subject to tolerance. That convention came over from the handrail trade with Hollander fittings. The one-line test: if you're hanging a light, you want pipe sized by diameter; if you're holding a bottle, you want a stainless well sized by length.

This piece is the second one. It matters to anyone cutting an opening in an ice bin or working out how many rails a station needs. By the end you'll be able to check any advertised bottle count against the pitch.

Product	Size	Material	Item Weight	Color	Choose if you need
GRIDMANN 32-inch	4"D x 32"W x 5.75"H	Stainless Steel	—	Silver	Best documented capacity
GRIDMANN 22-inch	8"D x 22"W x 9.75"H	Stainless Steel	7 pounds	Silver	Best bottles per foot
AmGood 15	15 x 4 x 6 inches	Stainless Steel	—	Metal	Best short run
Shopping Soda Premium Black	3.94"D x 15"W x 5.12"H	Stainless Steel, Powder Coating	1.8 pounds	Black	Best dark finish
AmGood 42	42 x 4 x 6 inches	Stainless Steel	—	Metal	Best long single tier
AmGood 48	48 x 8 x 10 inches	Stainless Steel	19 pounds	Metal	Best high volume
AmGood 36	8"D x 32"W x 10"H	Stainless Steel	11 pounds	Metal	Best mid-length double
SUNRISE	—	Stainless Steel	—	Stainless Steel	Best size options
Beaumont	155(h) x 108(w) x 817(d)mm.	Stainless Steel	2.1 kg	Silver	Best metric spec
Quality Industries	32 x 4.09 x 6.22 inches	—	5.9 pounds	—	Best for washing

Measurements come from the manufacturers. The “Choose if you need” call is ours.

Start here

GRIDMANN 32-inch, best for a standard well where you need a published bottle count against a known length — 8 one-liter bottles across 32 inches, or roughly three bottles per foot.

For everyone else:

• For a cramped station where you need 12 bottles but only have 22 inches of frontage to give up, so capacity has to go outward and upward instead of sideways: GRIDMANN 22-inch.
• For a single-station home bar or a short gap beside a sink where only about a foot of rail will physically fit: AmGood 15.
• For a visible home or hotel back bar where a mirror-polished rail would clash and you want the rail to disappear against dark cabinetry: Shopping Soda Premium Black.

Know this about the GRIDMANN 32-inch first: 20-gauge steel is thinner than the 18-gauge used on some commercial rails

Checking a manufacturer's bottle count against the pitch

Divide a rail's length by four and you get its nominal bottle count, using the average liquor bottle diameter Cabaret Design Group publishes. Where a listing gives its own figure, that sum is the check on it.

One correction worth making. Cabaret Design Group's own model station reaches 20 bottles using a 36-inch rail plus tiered underbar liquor steps, and the same source caps an efficient station at 10 to 12 feet overall. At the four-inch bottle diameter that source publishes, a 36-inch rail alone would give you nine. The steps do the rest of the work.

The bottles that break the four-inch rule

Cabaret Design Group's figure is an average, and averages do not describe a well loaded with fat or square-shouldered bottles. Because bottles cannot nest, a square bottle occupies more frontage than its base measurement suggests, so a rail loaded with them will hold fewer than the four-inch pitch predicts. No source in the evidence file quantifies that shortfall for any specific bottle or rail.

Nominal versus actual, on the bar side too

Bar rails carry the same nominal-versus-actual gap that film speed rail does. Summit's SpeedRail is sold at a nominal depth of 6.0 inches (15 cm) while its actual depth is 5.33 inches (14 cm); the unit measures 8.0" H x 18.0" W x 5.33" D, weighs 4.0 lbs, and is made of 304 grade stainless steel. That is the only bar rail dimensioned in the sources here, and no page states the length, height, depth or capacity range for bar speed rails as a category.

Where the differences change the build: depth, not length. Cabaret Design Group notes these things usually hang off drainboards, ice bins and three-bin sinks — surfaces that are already eating your reach. Length you can verify with a tape; width and depth you have to take from the listing.

Mounting geometry the listings leave out

A product listing doesn't tell you where on the bar die to put the rail. That's the number that decides whether a full well is workable, and it isn't a product spec at all — it's a bar spec. Cabaret Designers publishes several of the figures manufacturers skip.

• 12 to 14 inches off the floor for the bottom of the rail, per Cabaret Designers. Higher and the bartender's forearm has to lift on every pour; lower and the pull turns into a stoop.
• Top of the tallest bottle level with the working surface above it. Same source. That's the real mounting rule, and it means you measure your tallest bottle first, then set the rail — not the reverse.
• A 24-inch lateral envelope for underbar equipment. Everything the bartender touches without a step should fall inside it, which means any rail longer than that envelope reaches past a single station.
• Mounting hardware is unresolved. No source in the evidence file states the mounting hardware, bracket spacing, or the clearance a bar speed rail needs behind it.
• Clearance above a cooler door is the one people get wrong. Summit specifies its 18-inch SpeedRail for doors 24 inches or wider with a door depth of 1-5/16 inches — the rail has to clear the door's swing arc, not just its face.

Short that gap and the door fouls the rail. Cabaret Designers notes rails are typically hung off drainboards, ice bins and 3-bin sinks — all things with lids or doors that move. Check the swing before you drill. Worth reading alongside back bar shelving depth and row layouts, since the two runs compete for the same reach.

GRIDMANN 32-inch — Best documented capacity

• States capacity explicitly: 8 standard 1-litre bottles in 32" x 4" x 5-3/4"
• Keyhole mounting holes plus hardware included, so it can go on a wall, bar apron or ice bin front
• But: 20-gauge steel is thinner than the 18-gauge used on some commercial rails
• But: Hand wash specified rather than dishwasher

GRIDMANN 22-inch — Best bottles per foot

• Rated for 12 one-litre bottles in only 22" of length — the highest bottle-per-foot figure here
• Tiers joined with stainless brackets and predrilled keyhole holes with hardware
• But: 8" depth and 9-3/4" height project well into the bartender's body space
• But: 20-gauge rather than 18-gauge

AmGood 15 — Best short run

• 15" length fits gaps too small for 22" and 32" rails
• 18-gauge stainless steel despite the small size
• But: Holds only a handful of bottles, so a full well needs two units
• But: Listing gives no stated bottle count

Shopping Soda Premium Black — Best dark finish

• Powder-coated black over stainless, unlike every other rail here
• Listed at 4 bottles in 15" x 3.94" x 5.12"
• But: Care instruction is wipe with a dry cloth, and coated finishes can chip in service
• But: At 1.8 lb it is the lightest here, so it depends on solid fixings

AmGood 42 — Best long single tier

• 42" length covers a full well in one piece
• 18-gauge stainless and NSF-listed for commercial use
• But: Listing gives no bottle count for the 42" length
• But: Single tier means capacity comes from length, not depth

AmGood 48 — Best high volume

• 48" x 8" x 10" double tier gives the largest total capacity here
• 18-gauge stainless, NSF-listed, with a stated model number (AMGSR-48D)
• But: 19 lb and 8" deep, so it needs substantial mounting and eats reach space
• But: Listed as countertop/tabletop rather than wall mount

AmGood 36 — Best mid-length double

• Double bottle storage pocket in a 36" span, 8" deep and 10" high
• 18-gauge stainless, NSF-listed
• But: Listing's dimension field reads 32"W while the title and bullets say 36 in. — confirm before cutting an opening
• But: 10" height is the tallest profile here

SUNRISE — Best size options

• Offered in both 22-inch and 32-inch lengths for mixed station lengths
• Stainless steel, corrosion resistant
• But: Listing publishes no depth, height, gauge or bottle count
• But: No mounting hardware specified

Beaumont — Best metric spec

• Dimensions published in millimetres — 155(h) x 108(w) x 817(d) — for metric joinery
• Rounded corners reduce snagging in busy pass-behinds
• But: Narrowest published width here at 108mm, so wide-shouldered bottles may not sit well
• But: No gauge, bottle count or mounting hardware stated

Quality Industries — Best for washing

• Listing states it is commercial dishwasher safe, unlike the hand-wash-only rails here
• 32 x 4.09 x 6.22 inches at 5.9 lb — easy to lift out for cleaning
• But: No stated bottle count or steel gauge
• But: Bullet copy references another brand name (Rattleware), so provenance is muddled

Where 'buy the longest rail that fits' fails, and who each of these suits

Consider a double-tier rail. Its capacity per foot of frontage beats a single tier, but the projection costs reach: Cabaret Design Group reckons a double rail adds 5 inches to bartender reach and pushes a six-foot bartender into an extra 10 degrees of forward lean. So the trade-off is reach against capacity, though no source quantifies where it breaks even. The alternative is a single-tier run plus a tiered liquor step behind it: Krowne's KR24-12RD holds at least 12 bottles in a 12-inch space, which is where the deep capacity should live.

Why long runs lose to two short ones

Cabaret Design Group also caps underbar equipment inside a 24-inch lateral envelope, and that's the number that kills "buy the longest rail that fits". Past 24 inches of continuous rail, the far end sits outside that envelope. A long single run is therefore only worth it where a second person works the far end.

Every figure above is from published manufacturer and supplier copy, not from anyone who put a tape on a rail. Do that yourself before you cut an opening.
